6903 LLU MAX BO - MAX-Design, Black-Oxide, Radial, Suspension Bearing - 17mm x 30mm x 7mm
6903 LLU MAX BO - MAX-Design, Black-Oxide, Radial Suspension Bearing - 17mm x 30mm x 7mm -
Enduro Bearings pioneered MAX type bearings over 20 years ago for bicycles to address the challenges associated with mountain bike pivots. MAX-type bearings provide 35-40% more load capacity than standard radial bearings by utilizing a special design where the maximum number of balls are inserted into the bearing, via a custom ground slot in the races. The additional balls, combined with deep race grooves in these bearings for more lateral support for the twisting and multi-directional forces associated with mountain bike pivots. This MAX-type, Black-Oxide, bearing features deep-groove design races, with Grade 10 balls and full-contact, double-lip, labyrinth (LLU) seals for maximum protection against the elements, while keeping the 90% fill of Almagard extra high pressure grease inside and Black-Oxide/Magnetite treatment provides an extra level of corrosion resistance and extended worry-free performance.
This bearing has been used as a suspension pivot bearing by a number of bicycle brands.
This bearing is also commonly identified in the industry by these part numbers:
W272452
300020001
The Enduro line of bearings are available in high-carbon chromium steel, 440C stainless steel, ceramic-hybrid and XD15 with ceramic or stainless balls. Our bearings are always engineered with deepest groove races possible to accommodate the largest balls possible and feature dual-lip seals that ride in a micro-groove creating a full labyrinth to provide superior protection against the elements.
Static load - 937lbf / 4.17kN
Weight - 17.59g
6903 LLU MAX BO - MAX-Design, Black-Oxide, Radial Suspension Bearing - 17mm x 30mm x 7mm -
Enduro Bearings pioneered MAX type bearings over 20 years ago for bicycles to address the challenges associated with mountain bike pivots. MAX-type bearings provide 35-40% more load capacity than standard radial bearings by utilizing a special design where the maximum number of balls are inserted into the bearing, via a custom ground slot in the races. The additional balls, combined with deep race grooves in these bearings for more lateral support for the twisting and multi-directional forces associated with mountain bike pivots. This MAX-type, Black-Oxide, bearing features deep-groove design races, with Grade 10 balls and full-contact, double-lip, labyrinth (LLU) seals for maximum protection against the elements, while keeping the 90% fill of Almagard extra high pressure grease inside and Black-Oxide/Magnetite treatment provides an extra level of corrosion resistance and extended worry-free performance.
This bearing has been used as a suspension pivot bearing by a number of bicycle brands.
This bearing is also commonly identified in the industry by these part numbers:
W272452
300020001
The Enduro line of bearings are available in high-carbon chromium steel, 440C stainless steel, ceramic-hybrid and XD15 with ceramic or stainless balls. Our bearings are always engineered with deepest groove races possible to accommodate the largest balls possible and feature dual-lip seals that ride in a micro-groove creating a full labyrinth to provide superior protection against the elements.
Static load - 937lbf / 4.17kN
Weight - 17.59g
